Haas - VF-4SS

Haas - VF-4SS
  • Haas - VF-4SS

Prijsaanvraag
  • MerkHaas
  • Type/ModelVF-4SS
  • Voorraad nummer30321
  • Bouwjaar2023
  • WebsiteVF-4SS

Technische gegevens

  • Tafellengte1321 mm
  • Tafelbreedte457 mm
  • Langs X1270 mm
  • Dwars Y508 mm
  • Vertikaal Z635 mm
  • Posities ATC30
  • Aantal pallets0
  • CNC MerkHaas
  • CNC Modelx

HAAS VF-4SS Vertical Machining Centre with Haas 4th Axis Attachment. Year 2023
Table size 1321mm x 457mm. T Slot width 16mm. T Slot centre distance 80mm. No of T slots 5. X /Y/Z Axis 1270 mm/508/635 mm. Table loading 794 kg. Spindle Nose to Table (min/max) 102mm/737 mm. Maximum spindle speeds 15,000 rpm. Spindle power 22.4 kW. Spindle taper BT40.Rapids X/Y/Z  35.6 m/min. Maximum cutting feeds X/Y/Z 21.2m/min. ATC 30+1. Maximum tool dia. 127mm. Maximum tool dia. (full carousel) 76mm. Maximum tool length 279mm. Maximum tool weight 5kg. Toolchange time (tool to tool) 1.6 seconds. (chip to chip) 2.2 seconds. Coolant capacity 208 litres. Filtermist. Rigid tapping. Inline Direct drive. Extended Y-axis travel. Selection of spindle tooling.

Handelaar: GM MACHINERY LTD
