Okuma - LB 300 M

• Afdrukken
• Toevoegen aan favorieten

• MerkOkuma
• Type/ModelLB 300 M
• Voorraad nummer1148
• Bouwjaar2002

Technische gegevens

• Draaidiameter340 mm
• Draailengte1000 mm
• Posities revolverkop12
• CNC MerkOkuma
• CNC ModelOSP U 100L

Make                                                                                                 OKUMA
Type                                                                                                   LB 300 M
Year of manufacture                                                                  2002
Control system                                                                            OSP U 100L
Swing over bed                                                                             530 mm
Swing over cross slide                                                              420 mm
Max. turning diameter                                                              340 mm
Turning length                                                                               1000 mm
Travel X                                                                                             260 mm
Z                                                                                                          1020 mm
C                                                                                                         0.001°
Feed rate X/Z                                                                                 0.001 – 1000 mm/min
Rapid traverse X/Z                                                                      20/25 m/min
Spindle speed (2 gear ranges)                                              38 – 3,800 rpm
Spindle power                                                                              22/15 kW
Spindle bore                                                                                  80 mm
Bar capacity                                                                                  65 mm
Spindle nose                                                                                 A2-8
Spindle bearing diameter                                                       120 mm
Spindle torque                                                                              410 Nm
Number of tools in turret/driven                                         12/12
Tool interface                                                                                VDI 40
Driven tool speed                                                                       4,500 rpm
Driven tool power                                                                       5.5/3.3 kW
Chuck diameter                                                                          315 mm
Machine dimensions                                                                3310 x 1895 x 1925 mm
Machine weight                                                                           6,000 kg
Equipment:  Chip conveyor, Tailstock with hydraulic locking, Tool measuring equipment,

Price: € 15.000 (subject to prior sale)
Delivery: free loaded your truck Borrby, Sweden
Terms: Net cash before delivery

Handelaar: SCANTOOL AB

Prijsaanvraag
