Lumsden - LUMSDEN 93ML ROTARY TABLE SURFACE GRINDER

Технические данные

  • Диаметр магнитного стола0 mm
  • Высота шлифования0 mm
  • Диаметр шлифовального круга0 mm
  • Мощность 0 kW
  • ЧПУ Марка_Unknown / Other
  • ЧПУ МодельLUMSDEN 93ML ROTARY TABLE SURFACE GRINDER

LUMSDEN 93 ML Rotary Table Surface Grinder Serial Number: 93ML/103/13000 New 1996 Country of Origin: UK Possibly the last Lumsden ever made ! With auto sizing attachment, coolant and filtration unit. Segmental wheel dia 34" Segments per set 16" Table dia and grinding capacity 60" Magnetic table dia (Humphreys) 60" Max height wheel to Magnetic table 18" Minimum height of wheel to table 4.1/2" Spindle speed 450 rpm. Table speeds 16 and 5.1/2 rpm. Automatic feeds 10 rates .004-.040 ins/min. Power elevation 25 ins/min. Spindle motor 60 Hp @ 960 rpm 45 kW Table motor 6/2.1/2 HP @ 1440/480rpm. Feed motor 1/4 Hp @ 1440 rpm. Elevation motor 1 Hp @ 720 rpm. Coolant pump motor 1 Hp @ 1440 rpm. Overall height of machine 10'3". Floor space 13'8" x 10'4". Approx net weight 15 tons. Original cost in 1996 was 97,500 GBP

Дилер: BOWLAND TRADING LTD

BOWLAND TRADING LTD
Запросить цену
