Технические данные
Control: GE FANUC Series 16-T
Technical data
Number of axis total: 5
Longitudinal travel (X-axis): 500 mm
Transversal travel (y-axis): 400 mm
Vertical travel (z axis): 500 mm
B axis
Pallets:
number: 4
Length: 400 mm
Width: 400 mm
Maximum workpiece weight: 300 kg
Tool changer:
Number of tools: 96
Tool diameter max.: 80 mm
Diameter with free adjacent pockets: 160 mm
Tool lenght: 300 mm
Max. tool-weight: 12 kg
Time of tool changing: 2.5 sec
Average chip-to-chip time: 6 sec
Spindle nose: ISO: 40 DIN69871
Distance spindle nose to table: 100 - 600 mm
Distance from vertical
spindle to table: 20 - 420 mm
Spindle speeds:
stepless
from: 0 rpm
up to: 12000 rpm
Feed range: 1 - 12000 mm/min
Rapid traverse:: 20 m/min
Air connect: 6 bar
Voltage 50 Hz 3x: 400 Volt
Spindle power: 5.5 / 7.5 kW
Total power required: 60 kVA
Noise level: 75 dB (A)
Machine's weight about: 6000 kg
Overall dimensions machine:
Length: 4330 mm
Width: 3200 mm
Height: 2520 mm
Various accessories:
Coolant system: 500 l
Paper filter facility
Chip conveyor
Oil mist extractor
