Données techniques
Maschine wird teilüberholt mit Messprotokoll und Gewährleistung
innerhalb Deutschlands und Anrainerstaaten geliefert.
1 UR-RS 175 / 1500 standard version (T1, T2, T5, T7)
1 grinding wheel set T1 400x63x127mm
1 grinding wheel set T2 400x63x127mm
1 grinding wheel set T5 400x63x127mm
1 internal grinding device T7 0120 mm for HF spindles
1 centre height 250 mm
2 grinding head motor: drive power 10.0 kW
1 CNC control Heidenhain GRINDplusIT
1 Kel-ASSIST 100 PLUS (includes Kel-Assist 100 and thread calculation)
1 KEL-POLY, out-of-round grinding
1 KEL-NET for CNC control GRINDplusIT
1 B-AXIS GRINDplusIT: ‘CNC-controlled B-axis’ (standard)
1 GRINDplusIT: v constant 35m/s or 45m/s_adjustment of grinding spindle via control
1 T1, T2, T5, T7: T1 and T2: v=constant, T5: v=variable (Danfoss), T7: HF spindle
1 operating unit for 1x MFM or MFV spindles, VACON 22kW
1 x HF internal grinding spindle Fischer MFM 1224/42/31 re. HJND 21
1 x HF internal grinding spindle MFV 1260/4 re
1 x HF internal grinding spindle IBAG HF 33 S 60 P
1 tailstock with manual retraction
1 MICRO-ADJUSTMENT: tailstock lower section with micro-adjustment
1 spring-loaded quill insert
1 pneumatic relief for the tailstock
1 upper table flooding (standard)
1 reinforced workpiece spindle MK 5 DIN 55026 size 5’
1 C-AXIS: CNC-controlled C-axis to workpiece spindle box reinforced
1 lower part FIXED for the workpiece spindle box reinforced
1 KELPOS: Active longitudinal positioning MOVOMATIC, mounted on the grinding head
1 diameter measuring head Movomatic; DU200
1 measuring control unit Movomatic ES124 / digital
1 KELSET: KELSET tool measurement system, MARPOSS
1 Basic module for KEL-TOUCH cut-off sensor and KEL-BALANCE balancing device
1 KEL-TOUCH, cut-off sensor for diagonal/tandem
1 Full emulsion enclosure
1 Coolant cleaning gun connected to the table
1 Emulsion grinding mist extraction system
1 lubricant for initial filling
HF dressing device type IBAG on OT
Data from state of delivery without guarantee
