Technical details
x-travel: 3000 mm
y-travel: 1000 mm
z-travel: 860 mm
Control: Heidenhain iTNC-530
table-size: 3600 x 1050 mm
T-slots: 7 x 18
T - slots distance: 125 mm
distance table - lower edge spindle: 25-366 mm
table weight: 4200 Kg
b-axis: -105 °
c-axis: -360 0
rapid travel x/y/z: 30000 mm/min
rotary table: Durchm 1000 mm
max turning diameter: 1400 mm
number of spindle speeds: 9000 U/min/rpm
tool taper: ISO-50 DIN 69871-AD
spindle drive: 285 kW
max torque on the spindle: 240 Nm
tool change unit: AITEK 40 fach
: 20
handwheel: Ink
Shuttle operation: Inkl
Chip coveyor: Ink
Internal cooling system: 20 bar
total power requirement: 65 kW
weight of the machine ca: 248 t
dimensions of the machine ca: 8056 x 5496 x 3790 mm
