Technical details
Technical data
1 column execution
Table length: 400 mm
Table width: 300 mm
Longitudinal travel (X-axis): 200 mm
Transversal travel (y axis): 200 mm
Travel of the vertical slide: 250 mm
Passage from grinding motor to table: 270 mm
Max. grinding diameter: 15 mm
Vertical travel of grinding spindle:
stepless from: 2 mm
up to: 32 mm
Travel speeds:
steps: 2
from: 4.0 m/min
up to: 5.0 m/min
Possible grinding-spindle speeds:
stepless
up to: 120000 rpm
Voltage 50 Hz 3x: 380 Volt
Machine's weight about: 750 kg
Various accessories:
Centering microscop
Cross table
Length: 270 mm
Width: 170 mm
Lamp
Dealer: MULLER MACHINES SA
Price request
