Mori Seiki - NT3150 DCG 500C

Technical details

  • Turning diameter0 mm
  • Turning length0 mm
  • Positions ATC0
  • Workpiece weight0 kg
  • Motor power milling spindle0 kW
  • Bar feeder type0
  • CNC BrandFanuc
  • CNC Model3Li

INFORMATION

MSX-711 (Fanuc 3Li) for 5 axis simult., A2-5 40 pos. ATC type Capto C5

Bar-feeder LNS MoveS2


INVENTORY NR.2180207, MACHINE EQUIPPED WITH :
Control MSX-711 (FANUC 3Li) for 5 axes simultaneous machining, color screen 15’’ and dialog system MAPPS III
Memory capacity up to 1000 programs
Options : tools correctors (milling spindle), B tools life gestion, input of tools correctors G10,
3 interpolations, variable thread step (G34), circular threading, personalised macro, high precision contouring control (control II contour AI), card ATA 1 GB, offset tool for 5 axes machining
Chips conveyor (with chain) model/500
B-axis with direct motor (DDS)
ATC type CAPTO C5/ 40 positions
Tools to zero setting system with automatic arm for milling spindle
High-pressure cooling system type KNOLL with 500L tank, pump and paper filtration, for cooling through spindle centre
Cutting fluid coolant unit Type KNOLL
Linear measuring system for Axes X1 / Y / Z1
Tool monitoring system through control of main spindle motor and feed motors
Automatic workpiece measuring system with touch-test RENISHAW and macro B for use in Milling spindle
Light signal
Automatic machine stop
Workpieces receptor vat Ø52mm, L120mm
10 additional M functions
Flange for cylinder, threaded ring, traction tube, bore Ø 52
Clamping chuck HAINBUCH Spanntop Axzug Nova, with stop type 100 for pieces in chuck and for jobs in bars with passage, clamping head type 32, A2-5 direct mounting, adapter
Hydraulic chuck KITAGAWA, type BB206A5, Ø170mm, A2-5 direct mounting, passage Ø52mm
Bar-feeder LNS, Type Move S2
Diameter of roung bars : Ø8 – 80 mm, bars length : 700 mm – 1600 mm ; loading from the front ; longitudinal shift : 470 mm ; set of guidings Ø18-20 Ø24-26 and Ø28-30 ; pushers : 1x Ø 8 – 1x Ø 15 mm ; guiding devices for main spindle Ø 21 – 26 and 31 mm
Fire extinctor through carbonic gas type Tyco KLA III with 10kg CO2
Aspiration system ELBARON RON/A 3000 D-2H with full rest
