Technical details
x-travel: 760 mm
y-travel: 460 mm
z-travel: 560 mm
Control: Siemens Sinumerik 840D
b-axis: NC-Schwenkfräskopf
A-axis: NC-Rundachse
milling-head swivable /-: -120 / 30
Tool changer: 60
Cooling through the spindle: IKZ 40 bar
spindle turning speed range: 12000 U/min
spindle motor: 28/19 kW
tool taper: HSK-A 63
max torque on the spindle: 121 pm
total power requirement: ca 60 kVA
weight of the machine ca: 85 t
dimensions of the machine ca: - m
Universal bar machining center
- Siemens Sinumerik 840 D 3D path control - Powerline ShopMill
- Controlled NC swivel milling head (B-axis)
- NC rotary axis with integrated clamping system
- NC bar loader
- Slide/conveyor belt for parts disposal
- Coolant tank 600 ltr. with paper belt filter
- IKZ 40 bar through spindle center
- Rotating viewing window
- Tool breakage control
- Chip conveyor
- Tool magazine - Chain magazine with 60 magazine slots HSK-A 63
- Clamping devices for NC rotary axis (A-axis)
Translated with DeepL.com (free version)
The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Dealer: KEMMERICH WERKZEUGMASCHINEN GmbH
Price request
