  • FabrikatKapp
  • TypAST-305B
  • Lagernummer25764

Technische Details

  • Durchmesser300 mm
  • Modul0 mm
  • Axialer Hub420 mm
  • Länge0 mm
  • Kapazität (A)0 A

Specifications:

Maximum Clamping Length: 27.56" / 700 mm
Maximum Workpiece Diameter Capacity:  11.8" / 300 mm
Maximum Table Traverse: 21.56" / 550 mm
Maximum Diameter Grinding Wheel: 12" / 300 mm
Maximum Center Height:  6.1" / 155 mm
Infinitely Variable Table Speed:
-For Deep Grinding:  30-1000 mm / min
-For Surface Grinding: 3-16 mm / min
Grinding Spindle Speed:  2200 rpm
Axial Grinding Spindle Adjustment: 16.54" / 420 mm
Vertical Grinding Head Adjustment: 11.81" / 300 mm
Indexing Spindle Taper Morse 4 Or Steeper: 40
Pre-Selectable Single Infeeds:  0-9999
Machine Dimensions (L x W x H): 118" x 82" x 93"
Machine Weight: 7500 Lbs./ 3000 kg
