Tos - SKIQ 12 CNC

• Drucken
• Zu Favoriten hinzufügen

• FabrikatTos
• TypSKIQ 12 CNC
• LagernummerSKIQ-12-CNC
• Baujahr1990

Technische Details

• Tischdurchmesser1250 mm
• Drehdurchmesser1400 mm
• Drehhöhe1785 mm
• Motorleistung40 HP/kW
• Anzahl Werkzeugposition15
• Anzahl Paletten0
• CNC MarkeSiemens
• CNC Modell840 D

HYDRAULIC SELF CENTERING CHUCK Ø 1.250   MM.
MAX. WORKING Ø 1.400   MM.
MAX. SWING Ø 1.500   MM.
MAX. DISTANCE FROM CROSSRAIL TO TABLE 2.000   MM.
MAX. WORKING HEIGHT 1.785   MM.
MAX WEIGHT ON TABLE 12   TONS.
TABLE SPEEDS 3 ÷ 315   RPM.
TABLE MOTOR POWER 40   KW.
“C” AXIS
N. 1 VERTICAL TOOL FOR TURNING AND MILLING:
- RAM VERTICAL TRAVEL 1.000   MM.
- RAM SIZES 200 x 180   MM.
- MILLING MOTOR POWER 18,5   KW.
- MILLING SPEEDS 8,5 ÷ 3.312   RPM.
CROSSRAIL TRAVEL 1.250   MM.
CNC SIEMENS 840 D - 3 AXIS
TOTAL WEIGHT 25   TONS.
BUILT IN/RETROFITTED 1990/

COMPLETE WITH:
- 15 SEATS ATC
- VERTICAL MILLING HEAD
- 90° ANGULAR MILLING HEAD
- GRINDING HEAD
- TOOL-HOLDERS
- CHIPCONVEYOR
- FULL COVERED

Händler: NUOVA LOMBARMET SPA

Preisanfrage
