WEBSTER & BENNETT 72” EH Elevating Rail Vertical Borer
Table size 72”. Maximum swing 84”. Minimum/Maximum under cross rail 24”/48”. Vertical travel of cross rail 24”. Maximum height under turret face 59”. Turret Slide Vertical Travel 38”. Swivel of Turret Slide 35° Left & Right. Distance of Turret Travel on Cross Rail (Centerline of Chuck to Handwheels) 56”. 5 x Turret Positions. Dia. of Turret Hole 3”. Chuck Speeds (12) 3.8 – 83 rpm. Feeds (12) 0.008” – 0.375”. Manual, Powered Feeds with Rapid Traverse. Power of Main Motor 30HP. Elevation Motor 4 HP. Complete with Standard & Extra Height Chuck Jaws. Manual Peripheral Guarding.
Machine Dimensions L x W x H 120” x 156” x 163” High. Approximate weight 17 Tons
Händler: GM MACHINERY LTD
