Technische Details
Max longitudinal table travel 1.500 mm
Min. longitudinal table travel 150 mm
Max cross stroke 650 mm
Grinding length 1.300 mm
Grinding width 650 mm
Worktop 1300x500 mm
Distance between table and spindle axis 800 mm
Grinding wheel dimensions 400x127x50 mm
Hydraulic unit motor 7.5 HP
Spindle motor HP 10
Control unit tank capacity 240 litres
Refrigerant tank capacity 300 litres
Electric pump for refrigerant HP 0.35
Longitudinal speed m/1' 1-40
Cross speed m/1' 0-3
Automatic vertical feed 0.001 mm
Automatic cross feed 0.001 mm
Machine net weight 7000 kg
Machine overall dimensions (widthxdepthxh) mm 4.825x2.625x2.200
Complete with:
- Magnetic chuck 1.300 x 600 mm
- Dressing system over wheel
- Losma paper filter
- Service keys
USED MACHINE
Händler: BENTIVOGLIO MACCHINE UTENSILI S.R.L
Preisanfrage
